MMIX II wash trough mixer

Description
Chrome
Article number
333092
EAN
7391887269905
Flow 3 bar
4.5 l/m

PROPERTIES

  • ESS (energy saving system)
  • Ceramic cartridge with soft closing function
  • Adjustable flow control and temperature limiter
  • Eco (energy and water saving aerator)
  • Fixed spout, or 360°
  • Soft PEX® hoses with 3/8" connecting nut (stainless steel braided)
  • Lead Free material
  • Hole diameter Ø34-37 mm
Backflow protection unit type AA
K MMIX II tvattranneblandare.png
No. Art no. RSK Description
1 409389.AE 8344867 Lever, complete
2 409392.AE 8344866 Colour marking and mounting screw for lever
3 409391.AE 8344865 Cover nut
4 409393.AE 8345179 Lock nut for cartridge, incl service tool
5 439060.AE 8295361 Lock nut
6 S600253 8387149 Ceramic cartridge with service tool
7 S600298 3870203 Service tool
8 109016.AE 8295331 Spout nipple, complete, for fixed spout
9 139595.AE 8295313 Stop screw with limitation segment
10 409404.AE 8344859 Spout
11 131410.AE 8281509 Housing M22 int.
12 132205.AE 8281441 Aerator insert, 5 l/min at 200–600 kPa

Byggvarubedömningen

modal.bvb.desc;

Accepted installation instructions

Leadfree

Lead Free means that we have replaced the lead normally found in brass alloys. In this way, we get products with less environmental impact. Lead Free-labeled products contain less than 0.1% lead and are thus classified as lead-free.

Energyclass

The table below the product shows the energy class of the mixer. Certificates for energy labeling can be found under documents.
