MORA GARDEN - Frost-proof garden valve
Our garden valves are self-draining and therefore frost-proof even if you forget to dismantle the garden hose before the season with degrees below zero. However, we recommended that you always remove the hose and coupling when there is a risk of low temperatures.
- Description
- For wall thickness max. 1000 mm
- Article number
- 461760
- EAN
- 7391887240607
PROPERTIES
- Self-draining
- Key included
- With approved non-return valve
- Can be cut to suit wall thickness
- Wall bracket: H=110 mm, W=60 mm
- Approved backflow prevention device, EN-Standard EN 1717
Backflow protection unit type
Enter your e-mail address, then the parts list will be sent to your inbox.
No. | Art no. | RSK | Description |
---|---|---|---|
1 | 409411.AE | 8588938 | Spindle, L=400 mm |
1 | 409412.AE | 8588939 | Spindle, L=600 mm |
1 | 409413.AE | 8588940 | Spindle, L=1000 mm |
2 | 409415.AE | 8588937 | Valve body with cone and nut |
3 | 409414.AE | 8588941 | Fastening details |
4 | 708229.AE | 8530490 | Vacuum valve |
5 | 600162.AA | 8588935 | Headwork for loose key, retail packed |
6 | 600163.AA | 8588936 | Headwork for loose handle, retail packed |
7 | 630523.AA | 8588942 | Key, retail packed |
8 | 409211.AE | 8588943 | Handle |
Byggvarubedömningen
modal.bvb.desc;
Accepted installation instructions
Leadfree
Lead Free means that we have replaced the lead normally found in brass alloys. In this way, we get products with less environmental impact. Lead Free-labeled products contain less than 0.1% lead and are thus classified as lead-free.
